Min. Nhazi:1 Piece/Pieces
Ihe Nlereanya.: TDA150-005V01
TDA150-00TV0V0V01 A-Sift-LCD Crystal modul, atụmatụ na-acha ọcha na-acha uhie uhie, gụnyere onye ọkwọ ụgbọ ala, matte elu. Ọnọdụ arụmọrụ ya bụ -20 ~ 70 ~ 70 Celsius C, na ebe nchekwa ya bụ -30 ~ 80 ~ 80 ~ 80 ~ 80 ~ 80 ~ 80 ~ 80 Celsius. Mkpebi ngosipụta dị afọ 1600 (RGB) × 1200 (Uxga), a na-ahazi pikselụ na pikselụ na RGB vertical stristes. Ogo ngosi ya bụ 304.8 × 228.6 (W × H) mm, na akụkụ mpụga bụ 317.4 (w) mm.
Ọ bụ isi iyi ọkụ ọkụ na ndụ 30k, gụnyere ndị ọkwọ ụgbọala. TDA150-005v0v0v0v0v0v0v0v0v0v0v0v (2 lọ)
Ajụjụ: isnye ka anyị bụ?
A: R-Star sitere na Shenzhen, China, anyị bụ ọkachamara na-arụ ọrụ dị elu LCD, anyị nwere ike inye ndị ọrụ 1000, gụnyere ndị injin 20 nwere ahụmahụ. Companylọ ọrụ ahụ abanyela ISO9001 / ISO14001 / CCC / COHS / R & DELT ONTET-Vey ụlọ ọrụ dị elu nke ụwa.us America, Africa, Middle East, Europe, Central na South America na Oceania.Wo kwenyere na ọ bụrụ na ị nye anyị ohere ije ozi, anyị ga-abụ onye na-eweta ntụkwasị obi gị na China.
Ajụjụ: you na-emepụta (ụlọ ọrụ)?
A: Ee, anyị. Ọzọkwa ọrụ OEM / ODM dị ebe a.wlojujupụtara ịkekọrịta echiche gị na anyị. Ọ bụ ihe obi ụtọ anyị inye gị ngwọta kachasị mma maka gị.
Ajụjụ: Kedu ka anyị ga - esi kwe mma?
A: Oge nyocha ikpeazụ tupu mbupu ụgbọ mmiri.
| brand | BOE | Model name | TDA150-005V01 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1600(RGB)×1200 [UXGA] 133PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8×228.6mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10) | Outline dimension | 317.4 × 242 mm (H×V) |
| Signal interface | LVDS (2 ch, 8-bit) ,erminal, 40 pins |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
Otu nha na ihe nlereanya dị ka ndị a:
| brand | BOE | Model name | RT150X0M-N10 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768, XGA, 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8×228.6mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 1100cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) | Outline dimension | 326.5×253.5(H×V) |
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
| brand | BOE | Model name | DV150X0M-N16 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768, XGA, 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096(H×V) mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89(Min.)(CR≥10) | Outline dimension | 326.5×253.5×9.7mm(H×V×D) |
| Signal interface | 20 pins LVDS (1 ch, 8-bit) , erminal |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
| brand | BOE | Model name | RV150U0M-N00 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1600(RGB)×1200 [UXGA] 133PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8 × 228.6 mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Visual size | 307.2 × 231 mm (H×V) | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 317.4×242 mm(H×V×D) |
| Viewing Angle | 85/85/85/85(Min.)(CR≥10) |
|
|
| Signal interface | LVDS (2 ch, 8-bit),40 pins, erminal |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
Mkpesa na-ekpo ọkụ: Boe Tda150-000v0v0v0v0v0v0v0v0v0v0v0v0v0v0v0v01 15 " Ihuenyo dịpụrụ adịpụ, 15 4 TTT LTD ihuenyo , LCD Panel, LCD modul, ngosipụta dị elu.
12.3 "AV13Z7M-N11 Gosiputa LCD modul
21.5 "Boe Uv215fhm-N10 TTD LCD ONTY
