Njirimara Ngwaahịa

Ihe Nlereanya.: EV101WXM-N81

Nkwakọ ngwaahịa & nzipu

Ere Ngwa:

Piece/Pieces

Nmkpọ Okwu mmalite

Ev101wxm-N81 bụ modul 10,8 LCD na-eji teknụzụ A-SI TTD. A kwadobere ya na afụkụ ọkpọ, gụnyere draịva ọkwọ ụgbọ ala, enweghị mmetụ. Ngosipụta Mkpebi bụ 1280 (RGB) × 800 (WXGA), akụkụ ya bụ 16:10 (obosara: elu) na eriri rji. Ogo ngosi ya bụ 216.96 × 135.6 (obosara × 158.0 (obosara) mm, uru ngwaahịa ibu 505g (Ụdị.). N'ihe banyere ihe ndozi, ngwaahịa a na-eji akụkụ WE WERD sonye na ndụ 50k awa, gụnyere onye ọkwọ ụgbọ ala. Ihe ngosi akara ngosi EV101WXM-N81 na-eji ihe ngosi (1 lọl, ngụkọta), na-eji nkwụsị ọkụ, ihuenyo ihuenyo bụ 3.3V (ụdị. Ọ na-ahụkarị FV na-ahụ maka FV na-ahụkarị FV bụ 60Hz. Ọ na-arụ ọrụ na -20 Celsius C rue 70 Celsius C na-echekwa na -30 Celsius C rue 80 Celsius C. Dabere na ya nke na-acha odo odo duru na-egbu egbu, ndụ ahụ karịrị awa 50,000.

R-Star sitere na Shenzhen, China, anyị bụ ọkachamara na-emepụta ihe dị elu LCD, gụnyere nke na-eweta 100 na-egosi LCD, na-emegharị LCD, n'èzí Glie pụta ìhè LCD, ụlọ ọrụ na-egosi TTT-LCD, transperent LCD na ngosipụta, LCD nke abụọ, dị elu lcd na-agba agba agba agba agba agba. Na nkenke, ịrị elu nwere ihe karịrị afọ ise nke nnukwu ọkụ na teknụzụ na-acha odo odo na-egosi, 8 afọ nnukwu TFT module na mmepe, ihe mmepụta, afọ 10 nke akụrụngwa na-eweta akụrụngwa dị elu.

brand	BOE	Model name	EV101WXM-N81
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800, WXGA, 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96×135.6(H×V)mm	Surface treatment	/
Visual size	233.2×152.9×10.4(H×V×D) mm	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	233.2×152.9×10.4(H×V×D)mm
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 20 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

Otu ihe nlereanya na paradaịs dị ka ndị a

brand	BOE	Model name	EV101WUM-N20
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1920(RGB)×1200, WUXGA, 224PPI	Pixel configuration	RGB vertical bar
Display Area	216.806×135.504mm(H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	600cd/m²(Typ.)or customized	Outline dimension	229.45×149.22(H×V)mm
Viewing Angle	80/80/80/80(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 45 pins
work environment	Storage temperature: -25 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	AT101WSM-N11-58P0
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×600, WSVGA, 117PPI	Pixel configuration	RGB vertical bar
Display Area	222.72×125.28mm(H×V)	Surface treatment	Fog surface，Hard coating (3H)
Visual size	226×128.6(H×V)mm	Contrast Ratio	500:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	235×144.9×5.44mm(H×V×D)
Viewing Angle	80/80/60/70(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 6/8-bit) , 60 pins , FPC
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	EV101WXM-N82
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800 [WXGA] 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96 × 135.6 mm (H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	228.6 ×149.2×6 mm (H×V×D)
Viewing Angle	85/85/85/85(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 40 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C
