Ihe Nlereanya.: BA104S01-100
BA104S01-100 bụ ngwaahịa modul VCD nke 104 bu. (Boe) na iji teknụzụ A-LCD. A kwadobere ya na-acha uhie uhie, enweghị azụ azụ na-enweghị mmetụ. BA104S01-100 na-egosipụta mkpebi nke 800 (RGB) × 600 (SVGA), dị elu), dị elu na mpempe akwụkwọ nke No. Revo .1 tọhapụrụ BEE na December 12, 2014. Oghere ngosi ya dị elu bụ 218.4 (obosara) dị elu 176.9 (obosara) × 5.9 (ọkpụrụkpụ) mm, usoro ọgwụgwọ dị elu doro anya, ogo ngwaahịa dị arọ bụ 288g (ụdị.). Na-akwado ngwaahịa a na-eji akụkụ 6S6P waller akụkụ (elu), ndụ nke ọkụ bụ awa 50k, enweghị azụ azụ. BA104S01-100 na-agbachitere LVD (1 ch, 6/8/8/8 Pint, ngụkọta njikọ, na-agbaso voltaji, ihuenyo na-anya ihuenyo bụ 3.3v (ụdị ihuenyo). Ọ na-ahụkarị FV na-ahụ maka FV na-ahụkarị FV bụ 60Hz. Ọ na-arụ ọrụ na -20 Celsius C rue 70 Celsius C na-echekwa na -30 Celsius C rue 80 Celsius C. A na-atụ aro ihe nlereanya a maka iji ihe nlereanya na ọnọdụ ọgwụ n'ihi ihe dị ka awa 50,000 nke ndụ, ọnụ ọgụgụ nke usoro isi awọ, na atụmatụ ndị ọzọ.
| brand | BOE | Model name | BA104S01-100 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 800(RGB)×600 [SVGA] 96PPI | Pixel configuration | RGB vertical bar |
| Display Area | 211.2×158.4 mm (H×V) | Surface treatment | Clear |
| Visual size | 215.0×162.0 mm (H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 236×176.9×5.9 mm (H×V×D) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
Ihe ndị a bụ otu ụdị nha na paramita
| brand | BOE | Model name | AV104X0M-N10 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | 215.4 × 161.8 (H×V) mm | Contrast Ratio | 1100:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 230 × 180.2(H×V) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -40 to 95 °C Operation Temperature: -30 to 85 °C |
| brand | BOE | Model name | TDA104-001V02 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 900cd/m²(Typ.)or customized | Outline dimension | 235×173×10.5mm(H×V×D) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -55 to 85 °C Operation Temperature: -40 to 80 °C |
Mkpesa na-ekpo ọkụ: Boe Ba104S01-100 na-enwu 500nits TTT-LCD, Ohere, Ngosipụta Obere, Ngosipụta Outses, HD BASTES, 19IN LCD, Ihu LCD maka n'èzí , LCD Panel, LCD modul, ngosipụta dị elu.
